Electrical Connections
6-4
Digital Compact
To reset a Window low or Window high signal, release a new start
signal. In order to reset an O/L signal, you must use an external reset
signal or the reset button on the power supply. This will enable you to
start a new weld cycle.
Pin Assignment I/O Type Description
13 Reset Ext. < digital 24V PLC input signal
At 24V, the system is reset
14 Seek – digital 0V
15 Ampl. In < analog Amplitude control 0...100% (no ope-
ration below 20%)
Range: –10V...+10V (0V= 50%)
Tab. 6-3 Pin assignment of the J3 connector (15 pins)
