Branson DC 480 - Dimensions

Description of the Unit
4-5
Digital Compact
2002 BRANSON Ultrasonics Digital Compact Version 22.08.2002
4.4 Dimensions
4.4.1 DC Ultrasonic Power Supply Module DC 315/480
(30/40kHz)
Fig. 4-2 Dimensions of the DC power supply module (30/40kHz)
Side view
Front
(Dimensions in mm)
Single module
19“ drawer with 4 modules
Front Side view
Rear
Electrical power supply
Fan
Clearance
Clearance
133,4 (3 HU)
106,68 (21 DU)
426,72 (84 DU )
177,0 (4 HU)
approx. 50
approx. 50
for ventilation
Handle
