CHAPTER 3 CLUTCH
3
-
6
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
(1) Clutch housing
(2) Damper, pto
(3) Spring pin
(4) Hexagon socket bolt
(5) Stud bolt
(6) Spring washer
(7) Hex nut
(8) Hex bolt
(9) Hex bolt
(10) Hex bolt(sw)
(11) Pin
(12) Cotter pin
(13) Cover assy
(14) Hex ange bolt
(15) Pin, rubber
1
3
4
2
8
6
15
10
12
9
5
6
7
13
14
11
10
A42W301A
HST MODEL
42hW-201601
COMPONENTS
