CHAPTER 4 TRANSMISSION
4
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
3. OPERATION AND ADJUSTMENT
3.1 DIFFERENTIAL SYSTEM
1
2
3
5
6
4
F42W430A
Thedifferentialsystemistorotatetheleftwheelandrightwheelatdifferentspeedsforsmoothturning.When
turning,thissystemrotatestheinnerwheelintheturningdirectionslowerandtheouterwheelfastertoturn
thevehicleinthedesireddirection.
Also,whenawheelgotstuckinmud,itishardtoescapethepitsincethewheelinmudwithnofrictionrotates
atfasterspeedandthewheelonroadwithfrictiondoesnotrotateduetothedifferentialsystem.Topreventthis
situation,thevehicleisequippedwiththedifferentiallock.Thedifferentiallockmovesthedifferentiallockslide
toxthedifferentialcaseanddifferentialsidegeartogetherwiththepin,resultinginrotationofthesidegear
ontheothersideaswell.Therefore,thewheelsonbothsidesarerotatedatthesamespeedtoescapethepit.
Thedifferentialsystemconsistsoftheringgear(1),differentialcase(2),differentialsidegear(3),differential
pinion(4),differentialpinionshaft(5)anddifferentiallockslide(6).
