CHAPTER 4 TRANSMISSION
4
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
Whentheparkingbrakelever(1)ispulled,theparkingbrakecable(2)pullsthebrakeshaft(3).Then,theleft
brakerod(4),whichisconnectedtothebrakeshaft,activatestheleftbrakelever(5)whiletherightbrakerod
onthebrakepedalside,whichisxedtothebrakeshaftwiththespringpin,activatestherightbrakeleverto
producebraking force for each brake. Also,the parking brakeis coupled with thebrakepedals.Therefore,
pulling the parking brakelever with the brake pedals depressed can achieve sufcient braking force more
easily.
2
1
35HW402A
F36h/F42h
 (1)Parkingbrakelever  (2)Parkingbrakewire
