CHAPTER 4 TRANSMISSION
4
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
K42W482A
K42W483A
K42W484A
K42W485A
K42W486A
2. Unscrew the rear axle housing mounting bolts
(1)(7EA) and nuts (2)(2EA) to remove the rear
axlehousingassembly(3).
3. Pulloutthesnapring(1)oftherearaxlehousing
final pinion to remove the f inal pinion (2).
Unscrew the lock nut (3) and remove the rear
axle(4),nalgear(5)andtaperrollerbearing(6).
