Braun Aesculap ELAN 4 Instructions For Use/Technical Description

2
USA
Aesculap
®
ELAN 4 electro drill GA844
Legend
1 Product (ELAN 4 electro drill)
2 Rotational speed control button
3 Safety catch
4 Screw handle
5 Cable
6 Connector for control unit
7 Knob for left-rotation
8 Coupling
9 Arrow
10 Rotating sleeve
11 Adapter (for Kirschner wire protection sleeve and rinsing adapter)
12 Kirschner wire protection sleeve
13 Attachment
14 Rinsing adapter
15 Oil spray adapter
16 Symbol of the application part type in the display of the
ELAN 4 electro control unit
Symbols on product and packages
Contents
1. About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 Main functions and design characteristics. . . . . . . . . . . . . . . . 3
2.3 Application environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.4 Indications for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.5 Contraindications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Safe handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. Product description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.1 Scope of supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4.2 Components required for operation . . . . . . . . . . . . . . . . . . . . . 4
4.3 Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Working with the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6.1 System set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Caution
Observe important safety information such as warn-
ings and precautions in the instructions for use.
YYYY-MM
Maintenance label
Indication of the next maintenance appointment
(Date: Year-Month)
Machine-readable, two-dimensional code
The code contains a unique serial number which can be
used for electronic tracking of the individual instru-
ment. The serial number is based on the global stan-
dard sGTIN (GS1).
Manufacturer
Date of manufacture
Follow the instructions for use
Labeling of electrical and electronic devices pursuant
to directive 2002/96/EG (WEEE)
Classification Type BF
Reverse button clockwise/counterclockwise rotation +
oscillation mode switch
Motor speed control
Manufacturer’s batch designation
Manufacturer’s serial number
Manufacturer’s article number
Delivery quantity
Non-sterile medical device
According to US federal law, this product may only be
sold by a physician or by the order of a physician
Temperature limits during transport and storage
Air humidity limits during transport and storage
Atmospheric pressure limits during transport and stor-
age
R
L
Document No.: TA014436 - Version: 1.0 - Document ID: SOP-AIC-5002244 Date/Time Printed/Viewed: 2022-04-13 16:01 (CET)
Effective
