ELECTRONICS PV 101+/PV 102+ Service Manual
7–28 BREAS MEDICAL Doc. No. 003259 En Issue: X-1
R19 RESISTOR 18K 1% 1
R21, 67 RESISTOR 56R 1% 2
R22, 34, 72, 73, RESISTOR 1k 1% 6
R23 RESISTOR 3k9 1% 1
R25 RESISTOR 270k 1% 1
R26, 60, 71, 92, 98 RESISTOR 47k 1% 5
R28, 103 RESISTOR 220k 0,6W 2
R30 RESISTOR 68R 1% 1
R32 RESISTOR 5K6 2W 1
R33 RESISTOR 150R 1% 1
R35, 54 RESISTOR 22k 1% 2
R36 RESISTOR 270R 0,6W 1
R37, 40 RESISTOR 0R68 1W PR01 2
R38, 76, 77 RESISTOR 10R 1% 3
R39 RESISTOR 33R 1% 1
R42, 52, 62, 75, 78, 79 RESISTOR 100k 1% 15
R43 RESISTOR 4K7 2W 1
R48, 57, 64, 65, 87 RESISTOR 10k 1% 7
R50, 51, 70 RESISTOR 6K8 1% 3
R55, 59, 84 RESISTOR 2k2 1% 3
R58 RESISTOR 10k NTC B57621C103 1
R6 RESISTOR B57236-S200-M NTC 1
R61, 94 RESISTOR 470K 1% 2
R63, 91 RESISTOR 47R 1% 2
R66, 105 RESISTOR 68k 1% 2
R69 RESISTOR 12K 1% 1
R7, 15 RESISTOR 680R 1% 2
R8 RESISTOR 1M 0,6W 1
R82, 83 RESISTOR 0R1 0,6W 2
R85, 86 RESISTOR 47R O,6W 2
R88, 89 RESISTOR 100R 1% 2
R90 RESISTOR RXE185 / 3.5 A fuse (wire type) 1
S3 FUSE HOLDER Schurter 5x20m 1
TR1 TRANSFORMER 12uH PLA10 1
TR2 TRANSFORMER ETD34-3F3 1
Reference Description Quantity
