7.8.3 Component list – MDA board
TR3 TRANSFORMER ETD29 1
TR4 TRANSFORMER 7uH PLA10A7720R7D02 1
U1 IC LM324Y 1
U2, 6, 8 IC CNY17F-3 DIL6 3
U3 IC UC 3845D 1
U4 IC LM393D 1
U7 IC UC3825DW 1
U9 IC LM78L05ACM 1
Reference Description Quantity
C200 CAPACITOR 0,47u/25V 1
C201, 202 CAPACITOR 2,2nF Y1 DE1210E222M 2
C209, 232-234 CAPACITOR 4,7uF/16V 4
C210 CAPACITOR 10uF/6V 1
C213-217, 249-251 CAPACITOR 1nF NPO 11
C220 CAPACITOR 220u/50V 1
C221 CAPACITOR 0,47F FSOH 1
C222, 224, 225 CAPACITOR 10nF X7R 3
C223 CAPACITOR 10nF X7R 1
C226 CAPACITOR 0,1uF/100V MKT 1
C228 CAPACITOR 3,3nF X7R 1
C230 CAPACITOR 1uF/50V 1
C231, 243 CAPACITOR 1uF/35V 2
C236 CAPACITOR 330uF/25V CV-GX 1
C237 CAPACITOR 33uF/16V 1
C238, 245 CAPACITOR 0,1uF/50V X7R 2
C240-242 CAPACITOR 330pF NPO 3
C244 CAPACITOR 100uF/25V CV-GX 1
C246 CAPACITOR 4,7uF/35V ELYT D55 1
C273 CAPACITOR 10uF/50V MVKF55 1
C282-284, 203, 204 CAPACITOR 100nF X7R 35
D200, 202, 204, 209 DIODE BAS32 15
D203, 212, 213, 219 DIODE BAS85 5
Reference Description Quantity
