OPTIONAL THERMOSTAT
INSTALLATION
Installinganoptionalthermostatmayhelpyoumaintainaconstanthousetemperatureautomatically.Amillivoltthermostatis
requiredforproperoperation.AfixedwallmountorBreckwell’shandheldremotecouldbeused.(Contactyourdealeror
Breckwelltopurchasearemotecontrolorformoreinformation.)

 A
millivoltthermostatisrequired.
 Unplugthestovefromthepoweroutlet.
 Thetwothermostatwiresconnecttothethermostatterminalblockonthelowerleftsideofthebackofthecontrolpanel.
 Insertthetwowiresintheterminalsideandtightenthetwoscrewstosecure
thewires.
 Eitherwirecanbeinsertedintoeitherterminal.

THERMOSTATOPERATION
Afterproperlyinstallingthethermostat,movethemodeofoperationswitchonthefrontofthecontrolpanelintotheThermostat
mode.Plugthestovebackintothepoweroutlet.Youarenowreadytousethe
thermostatwithyourstove.

Thethermostatwilloperatethestoveina“High/Low”mode.Youwillstartyour
stovefollowingthestandardlightingdirectionspreviouslydiscussed.Youwill
thensetyourstovetothedesired“high”heatlevelsetting.Adjustthedamper
forthebestoperation;agoodstartingpoint
forthedamperisevenwiththeash
lip,whichisabouthalfwayout.The“high”levelcanbeanythingabovetheLow
settinguptothethirdheatlevel.

NOTE:Y
OUSHOULDNOTUSETH EFOURTHORFIFTHHEATLEVELWITHATHERMOSTAT.

Whenthethermostatiscallingforheat,theunitwillrunontheheatlevelthat
youhavethestovesetat.Whenthethermostatisnolongercallingforheat,the
stovewillautomaticallycycledowntothelowheatlevelsetting.Theunitwill
remainonthe
lowheatlevelsettinguntilthethermostatagaincallsforheat.At
thattimetheunitwillcycleuptotheheatlevelsettingthatthestoveissetto.
Keepinmindthattherewillbeathree‐minutedelaybetweeneachheatlevel
increaseastheunitgoesup
eachheatlevelsetting.

Theunitwillcontinuetofluctuatebetweenthelowheatlevelsettingandthe
highersettingthatyousetthecontrolpaneltountilyoupushtheON/OFFbutton
andturnthestoveoff.

Theunitwillfollowthenormalshutdownprocedure.

NOTE:I
FTHEPOWERISINTERRUPTEDTOTHESTOVEANDTHEFIREEXTINGUISHES,THESTOVEWILLREQUIREMANUALRELIGHTING.THE“HIGH”LEVELMUST
ALSOBERESET
.



