Breckwell SP6000 - Smoke Smell Coming Back Into The Home; Convection Blower Shuts Off and Comes Back On; Stove Will Not Feed Fuel, But Auger Light Does Come On

Chapter4–Troubleshooting
Page20
**CAUTION–UNPLUGTHESTOVEFROMALLPOWERPRIORTOATTEMPTINGTOSERVICETHEUNIT!
**
SMOKE SMELL COMING BACK INTO THE HOME
PossibleCauses: PossibleRemedies:(Unplugstovefirstwhenpossible)

1. Thereisaleakintheventpipesystem.

Inspectallventpipeconnections.MakesuretheyaresealedwithRTVsilicone
thathasatemperatureratingon500degreeForhigher.Also,sealjointswith
UL‐181‐APfoiltape.Also,makesurethesquaretoround
adapterpieceonthe
combustionblowerhasbeenproperlysealedwiththesameRTV.


2. Thegasketonthecombustionblowerhasgonebad.

Inspectbothgasketsonthecombustionblowertomakesuretheyareingood
shape.


CONVECTION BLOWER SHUTS OFF AND COMES BACK ON
PossibleCauses: PossibleRemedies:(Unplugstovefirstwhenpossible)

1. Theconvectionblowerisove rheatingandtripping itsinternaltemperature
shutoff.
Vacuumanydustoffofthewindingsandfanblades.Ifcleaningtheblowerdoes
nothelp,theblowermaybebad.

2. Circuitboardmalfunction. Checkthevoltagegoingtotheconvectionblower.Ifthereispowertothe
blower,thenthecontrolboardisfine.IfthereisNOTpowerbeingsenttothe
blowerwhenitshutsoffduringoperation,thenyouhaveabadcontrolboard.

STOVE WILL NOT FEED FUEL, BUT AUGER LIGHT DOES COME ON
PossibleCauses: PossibleRemedies:(Unplugstovefirstwhenpossible)

1. Fuseoncontrolboardblew Removethecontrolboard.Onthebackthereisonefuse.Ifitappearstobebad,
replaceitwitha5Amp125Voltfuse.Plugthestovebackinandtrytorunit.

2. High‐Tempswitchhastrippedorisdefective Waitforthestovetocoolforabout30‐45minutes.Itshouldnowfunction
normally.Ifnotusetheowner’smanualtolocatethehighlimitthermodisc.To
testifthethermodiscisbad,youcanbypassitasdescribed
previouslyforthe
POFthermodisc.

3. Badaugermotor Removethefuelfromthehopperandremovetheaugershaftfromtheauger
tube.Applylinevoltagetotheaugermotor.Ifthemotorwillnotturn,the
motorisbadorthehoppersafetyswitchhasfailed(seeabove).

4. Augerjam Visuallyconfirmthattheaugershaftisnotrotating.Ifitisnot,startbyemptying
thehopperoffuel.Thenpulltheaugershaftoutoftheaugertubefromthefront
ofthestove.Thencleartheaugertubeofallfuel.Visuallyinspectthe
auger
shaft.Makesuretheaugerflightsaresecurelyattachedtotheaugershaft.
Inspecttheshaftforbentflights,burrs,orbrokenwelds.Alsochecktheauger
tubeforthesignsofdamagesuchasburrs,roughspots,orgrovescutintothe
metalthatcouldhavecauseda
jam.Ifthepartsappearfine,reinstalltheauger
intheaugertubepertheinstructionsinthismanual.

5. Loosewireorconnector Checkallwiresandconnectorsthatconnecttotheaugermotor,highlimit
switch,hoppersafetyswitch,andtheMolexconnector.

6. Badcontrolboard Ifthefuseisgood,thewiresandconnectorscheckoutgood,andthehighlimit
switchdidnottrip,testforpowergoingtotheaugermotor.Ifthereisnotafull
currentgoingtotheaugermotorwhenthefuelfeed light is
on,youhaveabad
controlboard.
**CAUTION–UNPLUGTHESTOVEFROMALLPOWERPRIORTOATTEMPTINGTOSERVICETHEUNIT!**
