MAINTENANCE
16
4. Locate the two threaded holes (A) in the hub.
Place two M10 bolts (B) with a threaded length
of approximately 55mm.
5. Turn the bolts (B) until they touch the face of the
pumphead to which the hub is mounted.
6. Gently turn the bolts (A) alternately half a turn
clockwise to press the hub from the pumphead.
7. Once the bearing has been pressed off the
seat, the hub can be taken off the shaft.
4.5 Disassembling the bare shaft hub
1. Remove the retaining ring (A).
