– 20 – – 21 –
As mentioned above, if the battery has not been recharged
within the recommended amount of time, the LED indicator
on the watch dial will blink red. This blinking will last for
about six months. After that, the battery will be fully dischar
-
ged and therefore the indicator will stop blinking. However,
as soon as the watch is placed on the charger, the system will
automatically reactivate and can function normally after a
standard recharge cycle.
7. TECHNICAL SPECIFICATIONS
BEACON
Standard applied COSPAS-SARSAT
C/S beacon classification PLB CLASS 2
Transmission frequencies
121.5 MHz at
6
0°C/32°F
406.040 MHz
Transmission power 121.5 MHz:
6
30 mW
406.040 MHz:
6
3.2 W
Transmitter autonomy
6
18 hours
Operating temperature -20°C to +55°C
Power source 1 x Li-ion 4.2 V, 1.1 Ah
CHARGER/TESTER
Input 5 VDC 300 mA
Operating temperature -20°C to +55°C
For indoor use only, not water-resistant
Use only with specific AC/DC transformer supplied with the watch
PXX5024AWP-LMCB
XA-012AM-0500240
8.
GENERAL HANDLING PRINCIPLE
The different functions are selected by rotating the
crown. The latter has two axial positions: neutral (1) and
pulled out (2).
In the neutral position, rotating the crown enables you to
move from one function to another. The crown may be
turned forwards (clockwise) or backwards (anti-clockwise).
In the second position, rotating the crown enables you to
set the functions.
A brief push in neutral position (1) actions the functions.
9.
SELECTING AND SETTING FUNCTIONS
9.1
12H/24H display
You can choose between two display modes for the time
of day:
– 24H: military style
– 2x12H periods: a.m. and p.m.
Selecting and correcting:
Select the T2 (2
nd
timezone) function by
rotating the crown.
