Page #7 background imageLoading...
Page #7 background image
7
Main
Distribution
Panel
Transfer Switch
w/ Service
Disconnect
and Symphony
System
Hot Water
Heater
Air
Conditioner
Generator
Watt -
Hourmeter
Service Disconnect
Optional
50A Remote
Module
Optional
LV Remote
Module
Branch
Circuits
A/C
Thermostat
Example of 240VAC air
conditioner load controlled by
thermostat. Thermostat controlled
by low voltage remote module.
Not
for
Reproduction
