8 BRIGGSandSTRATTON.COM
G
N
Distribution Panel
L2
L1 IN
L2
L1 IN
G
N
N
L
Dual Low
Voltage Module
#1
#2
Thermostat
#1
#2
Low Voltage
Control Wiring
Example of two 240VAC air
conditioner loads controlled by
thermostat. Thermostats controlled
by dual low voltage remote module.
Example of 240VAC heat pump
load controlled by a dual low
voltage remote module.
Not
for
Reproduction
