Briggs & Stratton 100 AMP AUTOMATIC TRANSFER SWITCH - Page 9

9
L2 IN
L2 OUT
L1 IN
L1 OUT
Neutral IN
Neutral OUT
L2 IN
L2 OUT
L1 IN
L1 OUT
Neutral IN
Neutral OUT
Example of two 120VAC loads
controlled by 50 Amp remote
module.
Example of one 240VAC load
controlled by 50 Amp remote
module.
