5
Indicator Panel Description
1. Power indicator light – When illuminated, indicates that the dispenser is
on.
2. Hot water indicator light – When illuminated, indicates that the dispenser
is heating water.
3. Cold water indicator light – When illuminated, indicates that the
dispenser is cooling water.
Product Dimensions
Height Width Depth
104.4 cm (41.1 in.) 31.1 cm (12.2 in.) 35.4 cm (14.0 in.)
Package Contents
A
B
G
C
D
E
F
H
Part Description Quantity
A Filter flushing tube 1
B Shut-o valve tube (7 ft.) 1
C Filter housing (for filter flushing) 1
D Filters 4
E Feed water adapter (with extra nut) 1
F Plumber’s tape 1
G Drain saddle with foam gasket 1
H RO water outlet tube 1
Materials Needed
Wrench Electric drill with 1/4 in. drill bit
1 2 3
