ALTA EVOLUTION / EVOLUTION GT … User manual
ALTA EVOLUTION / EVOLUTION GT
6-6
6.5. MESSAGES
TYPES OF MESSAGES
6.5.1.
There are three types of messages:
 Information messages,
 Warning messages,
 Error messages.
MESSAGE LIST 6.5.2.
The following tables list the most common messages that may appear whilst using the machine together with the
possible solutions.
6.5.2.1. LIST OF WARNING MESSAGES
Problem No.
Message title
Display condition(s)
2
A new automation board has been detected.
Automation board replaced
5
Invalid IoBoard serial number or not tested board.
The automation board information is
not valid. Board not tested by the
supplier.
2016
Save settings?
2021
Insert tool 14-04-344 (D 90), Adjust the led position.
2024
Please insert Round 30 calibration in the center
2025
Please insert Round 60 calibration in the center
3002
Do you want to save this settings?
6001
Unable to start the storage service.
Database server login problem
6.5.2.2. LIST OF ERROR MESSAGES
When an error occurs, it is preferable to call your dealer’s Technical Services and to inform them of the exact error
number together with the associated text.
The list of the error messages which may be displayed when using your machine is given below.
Certain problems can sometimes be resolved without calling Technical Services.
The action to be taken is therefore indicated.
Problem No.
Message title
Display condition(s)
1
IO Board Connection Error.
The requested USB device cannot be found => Generates a
connection failure report
1
IO Board Connection Error.
The IO board does not respond to the connection requests =>
Generates a connection failure report
1
IO Board Connection Error.
The IO board short-circuit cannot be reset => Generates a
connection failure report
1
IO Board Connection Error.
Serial port opening failure => Generates a connection failure
report
1
IO Board Connection Error.
Connection loss detected by polling => Generates a connection
lost report
1
IO Board Connection Error.
Com port Rx lost => Generates a connection lost report
1
IO Board Connection Error.
Short-circuit detected on IO board => Generates a connection
lost report
1
IO Board Connection Error.
Board updating failure
2019
Layout error, slaving not possible
Led cannot be slaved during processing.
2019
Layout error
Initialisation inspection impossible
2026
Calibration Pros Error.
Camera images cannot be analysed. ->.
4001
PROS: Adjustment processing
error LED.
Either the led max control has been exceeded or the exposure
times are outside the range.
4002
PROS: Adjustment processing
error Pixel.
Pixel size cannot be calculated.
4002
PROS: Adjustment processing
error Pixel.
The difference in the pixel size in X and Y > +- 0.005mm
