ALTA EVOLUTION / EVOLUTION GT
8.1.9. SHAPE CREATOR SCREEN BUTTONS
: Axis moved downwards
: Axis moved to the right
: Axis moved to the left
: Axis moved upwards
: Deleting all the dot
: Offset ok, No oversize required
: Offset +, Apply an oversize of 0.10mm
: Offset ++, Apply an oversize of 0.10mm
or : Bridge positioning side
: Access to the Shape Creator function
: Zoom-in on the shape on the screen
: Re-do an image by live video
: Add points on the screen + number of points
: Activate/deactivate the magnetic function
: Return to Shape Creator screen
: Select a plastic frame
: Select a frame without circling
: Select a metal frame
