9
EMBLEM/ALLEGIANCE Canadian User Guide
Rear-Facing Installation with LUAS
9 All connections are secure and straps are not twisted.
9 No more than
7.5 cm (3 in.)
of the base hangs over the
edge of the vehicle seat.
9 The anti-rebound bar is properly installed (see page 26).
9 The child seat cannot be moved front to back or side to
side more than 2.5 cm (1 in.) at the belt path. If the child
seat is not secure, repeat installation or use a dierent
seating location.
9 The child seat is correctly installed when angle guide line
is parallel to the ground when the car is parked on a level
surface. After the child is secured, the recline angle of the
child seat should be 30° – 45° from vertical (not to exceed
45°) when the car is parked on a level surface. See “Seat
Positions” on pages 24 - 25.
9 Tether webbing is stored in storage pouch. See page 30.
