Britax EMBLEM - Using a Lock-Off; Infant Positioning Pillow; Seat Positions

24
BRITAX Child Safety, Inc.
Seat Positions
This child seat has 3 positions. To adjust, pull the recline
handle then rotate the child seat shell into the desired
position. Release the recline handle, then verify the child
seat has locked into position.
NOTE: Set the seat position BEFORE installing.
90°
0°
Position 1
90°
0°
Position 2
90°
0°
Position 3
Using a Lock-O
NOTE: Using a lock-o is optional if your vehicle seat belt
system has a locking feature. See your vehicle owner’s
manual for more information.
To Open:
1. Open the locking tab.
2. Open the clamp.
IMPORTANT: Both parts
of the lock-o must be
opened to secure a vehicle
belt.
To Close:
1. Close the clamp over the
vehicle belt.
2. Push down on the locking
tab where indicated until
a click is heard.
Infant Positioning Pillow
The infant positioning pillow is designed to provide better
harness fit and comfort for infants using this child seat.
IMPORTANT: The infant
positioning pillow must be used
with infants weighing up to 10
kg (22 lbs) when using a child
seat in a rear-facing position.
Do not use over 10 kg (22 lbs)
or in a forward-facing position.
Clamp
2
1
Locking
Tab
2
1
Locking
Tab
Vehicle
Belt
Clamp
