Britax EMBLEM - Rear-Facing Installation; LUAS Installation Steps

8
BRITAX Child Safety, Inc.
Rear-Facing Installation
1. Remove the lower
connectors from the
storage slots in the base.
Press the adjuster release
button and pull the strap
to full length. Repeat for
the second strap.
2. The anti-rebound bar is
required for rear facing
installations. Attach the
anti-rebound bar (see
page 26).
IMPORTANT: Keep
fingers away from the anti-
rebound bar connection
points to avoid finger
entrapment or pinching.
3. Recline the unoccupied
child seat to position 3
and place rear-facing on
the vehicle seat (see page
24). Ensure that no more
than 7.5 cm (3 in.) of the
base hangs over the edge
of the vehicle seat .
4. Firmly press the lower
connectors onto the
adjacent lower anchors.
A click helps confirm
attachment.
5. Push the child seat
down while pulling each
lower connector strap to
tighten.
1
7.5 cm
LUAS Installation
IMPORTANT: The provided infant positioning pillow must
be used for children weighing 10 kg (22 lbs) or less in a
rear-facing position. Do not use over 10 kg (22 lbs) or in a
forward-facing position.
IMPORTANT: The anti-rebound bar is required for rear
facing installations.
