33
EMBLEM/ALLEGIANCE Canadian User Guide
Seat Cover
Removing the Cover
Never remove the buckle tongues from the harness.
They cannot be reattached after removal. If reassembled
incorrectly, the child seat may not perform as intended.
1. Loosen and unbuckle the
harness.
a. Lift harness adjuster
lever.
b. Pull both harness
straps forward.
c. Unbuckle the
harness.
2. Open the chest clip.
a. Press tabs
b. Pull apart
3. Remove the infant
positioning pillow if
necessary.
4. Remove the belly pad and
buckle.
a. Lift the cover from
the seat to find
the buckle strap
connection.
b. Remove the buckle
strap by turning
the buckle retainer
sideways and
routing it out of the
front buckle slot in
the child seat (see
page 36).
c. Slide the end of the
belly pad over the
comfort foam on the
seat.
4c
4b
4a
a
b
1b
1a
IMPORTANT: Before each use, check this car seat and its
components to make sure they are in good condition and
good working order.
Maintenance
