Brivo ACS5000-E - Verify Shipping Contents

Brivo ACS Installation Manual ACS5000-E
ENG-WI-001 © 2005 Brivo Systems, LLC. All rights reserved. Page 6
 Verify shipping contents.
1. Locate and check the contents of the 2-Door Ethernet Control Panel kit (#ACS5000-E).
The control panel kit should contain the following parts:
a) 1 metal chassis (MCH-CHA-0001). Packed inside the chassis are:
• 1 cardboard box containing the MAIN BOARD (#1181-01-0101A) and an
Identity Label (#ENG-LBL-0004).
• 1 cardboard box containing a power supply board (#1181-01-0104A).
• 1 cardboard box containing accessories, including:
o 1 AC transformer (#ELC-XFM-AMS1)
o 1 7 Ah lead-acid battery (#ELC-BAT-B7001)
o 1 power cable assembly (#ELC-PWR-A001)
o 2 MOVs (Metal Oxide Varistors), (#ELC-MOV-M001)
o 16 EOL (End of Line) resistors (#ELC-EOL-R001)
o 2 10-inch 18-gauge battery wires (1 red, 1 black), with female
spade-type connectors (#ELC-BAT-W001)
b) 1 lock and key set (#MCH-LCK-0001)
c) 5 screws for power supply (#MCH-SCW-0001)
d) 5 standoffs for the MAIN BOARD (#MCH-SFF-0001)
e) 1 tamper switch assembly (#ELC-TMP-A001)
f) 1 documentation set, including:
• Installation Manual (this document, #ENG-WI-001)
• Wiring Guide (#ENG-WI-002)
• Networking Guide (#ENG-WI-003)
attached to the end of this document
• Installation Worksheet (#ENG-WI-004)
• Quick Start Guide (#ENG-WI-005)
2. If additional DOOR BOARDs have been ordered with the control panel, locate and check
the contents of each 2-Door Board Kit (#ACS5000-DB).There may be up to 15 of these
kits, and each should contain the following parts:
a) 1 DOOR BOARD (#1181-01-0102A).
b) 5 standoffs for the DOOR BOARD (#MCH-SFF-0001)
c) 6 EOL resistors (#ELC-EOL-R001)
d) 2 MOVs (Metal Oxide Varistors), (#ELC-MOV-M001)
e) 1 power cable assembly (#ELC-PWR-A001)
3. If additional INPUT OUTPUT BOARDs have been ordered with the control panel, locate
and check the contents of each INPUT OUTPUT BOARD Kit (#ACS5000-IO).There may
be up to 15 of these kits, and each should contain the following parts.
a) 1 INPUT OUTPUT BOARD (#1181-01-0103A).
b) 5 standoffs for the INPUT OUTPUT BOARD (#MCH-SFF-0001)
