Brivo ACS Installation Manual ACS5000-E

c) 8 EOL resistors (#ELC-EOL-R001)

d) 1 power cable assembly (#ELC-PWR-A001)

4. If additional expansion chassis have been ordered with the control panel, locate and

check the contents of each Expansion Chassis Kit (ACS5000-EXP). Each expansion

chassis can hold up to two boards, including any combination of door and/or Input Output

boards. There may be up to 7 Expansion Chassis kits, and each should contain the

following parts:

a) 1 metal chassis (MCH-CHA-0001)

b) 1 lock and key set (#MCH-LCK-0001)

c) 5 screws for power supply (#MCH-SCW-0001)

d) 1 door label showing wiring and setup guide (Inside Door Label – Expansion

(#ENG-LBL-0003)

e) 1 tamper switch assembly (#ELC-TMP-A001), including:

• 1 tamper switch (#ELC-TMP-S001)

• 2 wires (#ELC-TMP-W001)

• 1 header connector (#ELC-TMP-HC01)

f) 1 power supply board (#1181-01-0104A).

g) 1 AC transformer (#ELC-XFM-AMS1)

 Plan your installation.

1. Determine the size of your control panel.

a) In addition to the control chassis, which contains the MAIN BOARD, there may

be up to seven expansion chassis.

b) The control chassis contains the MAIN BOARD, which also serves as a 2-door

board, and may also contain either a DOOR BOARD or an INPUT OUTPUT

BOARD.

c) Each expansion chassis may contain one or two boards: one DOOR BOARD,

one INPUT OUTPUT BOARD, two DOOR BOARDs, two INPUT OUTPUT

BOARDs, or one DOOR BOARD and one INPUT OUTPUT BOARD.

• Each DOOR BOARD has two terminal nodes, each of which contains a

complete set of terminals for controlling a door. This means that each

DOOR BOARD can be used to control two doors.

• The same inputs and outputs that drive a door can also be used for other

devices as configured through Brivo Online. In other words, DOOR

BOARDs do not need to be used to control doors.

WARNING: Door Wiring

If a node is to be used for a door, do not connect any other device to the following

terminal blocks: REX & DOOR, DOOR LOCK 250MA, DOOR LOCK RELAY, and

READER.
