9-3
7. After cleaning, completely dry. Lubri-
cate O-ring with clean liquid shorten-
ing. Install O-ring in O-ring groove.
SPLASH SHIELD
Allow cover assembly to
cool before cleaning. Hot
surfaces could cause serious burns.
If your unit is equipped with a two piece
splash guard, clean it according to the fol-
lowing instructions:
1. OPEN cover and slide back 2 to 3
inches.
2. Rotate cover handle (1) to a centered
position.
3. Loosen screws (2) attaching back
splash shield (3) to splash shield (4).
4. Slide splash shield (4) forward and up
towards the end of the cover handle
(1).
5. Clean the top and underside of splash
shield and top of the cover.
Make sure back splash
shield (3) and splash
shield (4) are assembled correctly after
cleaning. The cover may not close cor-
rectly if they are not.
6. Assemble in reverse order.
Filter Pan & Cover
Wipe all oil off filter pan and both sides of
the filter pan cover.
Rags or paper containing
cooking oil can catch fire
if exposed to heat. Laundering will not
remove the oil. Dispose of all oil-soiled
papers and rags in a trash container that
is in a ventilated area away from all
cooking equipment or other heat
sources such as direct sunlight.
broaster.com Manual #17269 8/13 Rev 5/14
