Back-Up Alarm:
Provides pulsating sound from a 102 dB alarm when ignition is on and transmission is in
reverse. Conforms to SAE J994B.
Outrigger Alarm System:
102 dB alarm with alternating two-tone sound is actuated when the OUTRIGGER
DOWN, OUTRIGGER BEAMS OUT or OUTRIGGER BEAMS IN controls are operated.
Emergency Stop Switch:
A two-position push button switch located on the left-hand side of the dash panel.
Designed to stop the engine and shut down the hydraulic system.
Optional Electrical Accessories:
Strobe Lights:
Two yellow strobe lights, one on each side of counterweight, for high visibility all around
crane. Flashes 60-120 times per minute. Includes operator controlled switch. Net
Weight: 15 pounds (7kg)
Boom Work Lights:
Two LED work lights, one on left side of boom to light boom tip, and one on right side of
the turret to light ground, under boom tip. Includes switch at operator's station. Net
Weight: 10 pounds (5kg)
Hydraulic System:
Standard:
Two piston pumps, mounted on and driven by the main transmission, delivers a
combined flow of 103 GPM (390 L/min) at 4000 PSI (275.8 bar) and 2600 RPM engine
speed. System protected by relief valves, suction-line strainers, and a 150 GPM, 10-
micron return-line filter.
Hydraulic Reservoir:
156-gallon (509 L) capacity, equipped with 10-micron breather on top and oil level gauge
on side.
Boom:
Standard:
Four-section, high strength steel construction, equipped with lubricant -filled bearing
pads for efficient support and extension. Hydraulic cylinder coupled with double runs of
high-strength leaf chain, extends and retracts the second, third, and fourth stages
porpotionally. The telescope cylinder and the boom elevation cylinder are equipped with
cylinder-mounted holding valves. Boom angle indicator is provided on the left side of
the boom.
Boom Rotation:
Heavy-duty bearing rotation gear with external teeth supports boom. Rotation is
powered by hydraulic motor and worm gear drive. Rotation gearbox may be adjusted
as wear occurs, to minimize backlash. Boom is attached by steel turret weldment.
Main Hoist:
Hydraulically-powered, turret-mounted hoist to provide a bare-drum line pull of 15,000
lbs (6804 kg) and a speed of 167 feet-per-minute (50.9 m/min). Hoist drum is a grooved
12.99-inch (32.99 cm) diameter by 19.61 inches (49.81 cm) long.
