3-8
FLUID VOLUME
Hydraulic reservoir – 160 gallons (606L)
Fuel tank – 75 gallons (284L)
Planetary hoist – 2.5 gallons (9.5L)
Axle – Differential Housing – 5.4 gallons (20.5L), Hubs – 0.5 gallons (1.85L)
Transmission – 5 gallons (19L), not including oil cooler and lines.
Engine oil capacity – 10.5 quarts (10L)
Engine cooling system – 14 quarts (13.2L), fill to bottom of fill neck in surge tank.
RT-400-A LUBRICATION CHART
