Broderson RT-400-A - Instruments, Controls, and Systems; Instruments and Control Displays

2-9
INSTRUMENTS AND CONTROLS
The RT-400 instrument panel is equipped with a monitor display that includes warning lights
and push buttons to change display screens. The display includes:
There are other display screens that are accessible on the main display, they are:
Outrigger Page - Shows the hydraulic pressure on each outrigger. This page
can be accessed through pressing the icon or the physical button below the icon
on the 15-button panel. This page has a digital level that represents the machine
level, as measured by the angle in diameter, mounted to the underside of the
bearing plate.
Steering Page - Shows the current steer mode that is being operated; or the
steer mode that has been requested. This page can be accessed through
pressing the icon or the physical button below the icon on the 15-button panel.
Diagnostics Page - Shows a full set of system diagnostics, which includes but is
not limited to:
a. Status for Analog and Digital Inputs and outputs to aid with trouble
shooting.
b. A fuse and relay diagram that will show the operator when a fuse or
relay has an issue, and highlight which fuse or relay it is for easy
locating.
This page can be accessed through pressing the icon or the physical button
below the icon on the 15-button panel.
Climate Page – Provides controls for the heating and cooling in the operator
compartment. This page can be accessed through pressing the icon or the
physical button below the icon on the 15-button panel.
Home Page – Selecting this icon or the associated physical button below the icon
on the 15 button panel will return the operator to the main page of the system.
 Machine Fuel Level

Machine Hydraulic Temperature
 System Voltage
 Transmission Gear Indicator
 Seat Switch Indicator
 Parking Brake Indicator
 Brakes Charging Indicator
 Low Brake Pressure
 Engine Hour Meter
 Engine RPM Tachometer
 Engine Coolant
 Engine Oil Pressure
 Engine DEF level
 Engine After-treatment Manual
Regeneration Button
 Engine After-treatment
Regeneration Delay Button
 Engine RPM Set-Points
 Engine RPM Incremental Adjust
