NORMAL GAUGE READINGS
The RT-400 is equipped with two, full color touch screen displays. The main display is on
the right side of the cab. This display is programmed to be the primary controller for the
machine. It will monitor engine information directly off the SAE J1939 CAN bus network
provided by the engine manufacturer. The display is also connected to other inputs, such as
the fuel tank sender and hydraulic tank temperature sensor, to provide a wide variety of
valuable information to the operator. Much of the run-time information is combined together
in the main screen where the Operator will find many common vehicle parameters. Other
screens with specific information can be scrolled to as needed, including: outrigger screen,
steering screen, HVAC controls screen, and a diagnostics screen. Five buttons are provided
below the display to serve as redundant buttons to the touch screen icons for navigation to
these various screens as needed.
Main Screen vehicle parameters
:
This display is considered the "home" screen and displays real-time data for each parameter.
Engine and system fault codes will display on the "home" screen as a pop-up window when
those events occur. It also has warning and shutdown icons that will turn on when a critical
threshold has been exceeded. These icons include the following:
 Battery Charging system Error
 Engine Warning Light
 Engine Shutdown Light
 Engine Grid Heater / Wait to Start Light
 Engine Coolant Level Indicator Light
 DEF Level Indicator
 DEF Level Warning Light
 After-treatment Regeneration Active
 After-treatment Regeneration Disable
 After-treatment System Temperature/Regeneration Underway Indicator Light
W A R N I N G
Vapors can be formed inside fuel tank and cause buildup of pressure that can result in
sudden expulsion of fuel and fuel vapors from the filler neck when the fuel cap is
removed from a hot tank. Remove cap slowly. Fuel spray may cause injury.
 Engine RPM Incremental Adjust
 Machine Fuel Level
 Machine Hydraulic Oil Temperature
 System Voltage
 Transmission Gear Indicator
 Seat Switch Indicator
 Parking Brake Indicator
 Brakes Charging Indicator
 Engine Hour Meter
 Engine RPM Tachometer
 Engine Coolant
 Engine Oil Pressure
 Engine DEF level
 Engine After-treatment Manual Regeneration
Button
 Engine After-treatment Regeneration Delay Button
 Engine RPM Set-Points
