Adjusting the Mark Sensors
If the cutting position is misaligned when cutting
using the “CaptureMat” function, the machine can
be manually adjusted.
● If the cutting position is shifted upward or
downward from the actual pattern:
Refer to step
b.
● If the cutting position is shifted right or left from
the actual pattern:
Refer to step
c.
Note
• Check the shift of the cutting position with the
mat in the same orientation as when it was fed
out.
a From the machine’s settings screen, select
[3.Basic Setup], then [3.Mark Sensor].
b Press or to select the vertical
adjustment value, and then press .
 The following message appears.
Example: If the vertical adjustment value was changed
from 0 to 2
(Before change After change )
• If the cutting position is shifted upward, increase
the value. If the cutting position is shifted
downward, decrease the value.
c Press or to select the horizontal
adjustment value, and then press .
 The following message appears.
Example: If the horizontal adjustment value was
changed from 0 to -5
(Before change After change )
• If the cutting position is shifted to the left, increase
the value. If the cutting position is shifted to the
right, decrease the value.
Vertical 0
Horizontal 0
