Troubleshooting and routine maintenance
65
Paper is jammed at the back of the
machine C
a Press the cover release lever to open
the front cover.
b Take out the drum unit and toner
cartridge assembly.
c Open the back cover.
d Pull the tabs at the left and right hand
sides toward you to open the fuser
cover (1).
e Using both hands, gently pull the
jammed paper out of the fuser unit.
f Close the back cover.
1
