DCP-J572DW
1. 1.8"(44.9 mm) Liquid Crystal Display (LCD)
Displays messages to help you set up and use the machine.
2. Number of Copies
Press + to increase or - to decrease the number of copies.
3. Warning icon
The warning icon lights up when there is an error or maintenance message.
4. Settings buttons
Clear/Back
Press to go back to the previous menu level.
Settings
Press to access the main menu.
OK
Press to select a setting.
WiFi
Press to configure the wireless settings while the machine is idle.
a or b
Press to scroll through the menus and options.
d or c
• Press to move the cursor left or right on the LCD.
• Press to either confirm or cancel a procedure which is in progress.
5. Mode buttons
SCAN
Press to switch the machine to Scan mode.
Press to switch the machine to Photo mode.
WEB
Press to switch the machine to Web mode.
9
