3-5
Confidential
Toner box drive cover Taptite bind B M4x12 2
0.8±0.1 (8±1)
Toner sensor PCB ASSY Taptite bind B M3x8 1
0.4±0.05 (4±0.5)
Holder toner box Taptite bind B M4x12 3
0.8±0.1 (8±1)
Lift cam guide Taptite bind B M4x12 1
0.8±0.1 (8±1)
Main shield plate Taptite cup S M3x8 SR 1
0.5±0.1 (5±1)
Screw pan (S/P washer)
M3x12DB
1
0.5±0.1 (5±1)
LVPS shield plate Taptite cup S M3x8 SR 1
0.55±0.05 (5.5±0.5)
Taptite bind B M4x12 1
0.8±0.1 (8±1)
Frame R unit Taptite cup S M3x6 SR 1
0.5±0.1 (5±1)
Taptite bind B M4x12 2
0.8±0.1 (8±1)
Registration front/rear actuator
holder ASSY
Taptite bind B M3x10 1
0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
