2.2 Drum Cleaning

Attach the drum cleaning sheet kit (SP) (D011B4001) on the drum unit, and drum cleaning

starts.

The insertion supplied with the drum cleaning sheet kit (SP) (D011B4001) is published on the

next page.

Note:

• The drum cleaning sheet is supposed to be used only one time.
