3-23

Confidential

9.5 Side cover R

(1) Release the Hooks A, B, and the Hook C on the Side cover R in order of the arrow A to C,

and remove the Side cover R.

Fig. 3-15

Hook C

Hooks B

Side cover R

Hooks A
