5-2
Confidential
1.1.2 Method of entering end-user accessible maintenance mode
The maintenance mode functions should only be accessed by service personnel. However,
end users are allowed to use some of these functions under the guidance of service
personnel over the phone. End users can only use the functions shaded in the table “1.2 List
of Maintenance Mode Functions” (Function code 09, 12, 25, 45, 77, 80, 82, 91).
<Operating Procedure>
LCD models
(1) Press the [OK], [Go], and [OK] in this
order while the machine is in the
ready state. “0” is displayed on the
LCD.
(2) Press the [] or [] several times
until the desired maintenance mode
function is displayed on the LCD.
Check that the desired maintenance
mode is displayed on the LCD, and
press the [OK].
(3) Each time the selected maintenance
mode function is completed, the
machine returns to the ready state
automatically. For function codes 12,
25, 45, 80, and 82, pressing and
holding the [Go] returns the machine
to the ready state.
LED models
(1) Check that the front cover is closed.
(2) Press and hold the [Go], and turn ON
the power switch. The Toner, Drum,
and Paper LEDs light.
(3) Release the [Go]. All LEDs go out.
(4) Press the [Go] for the assigned
number of times to enter maintenance
mode (While you are pressing the
[Go], the Ready LED remains lit).
(5) Each time the selected maintenance
mode function is completed, the
machine returns to the ready state
automatically.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-L2372DN and is the answer not in the manual?

Brother HL-L2372DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 6, 9, 16, 25
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)9 s
Print speed (black, normal quality, A4/US Letter)34 ppm
Duplex print speed (black, normal quality, A4/US Letter)16 ppm
Sustainability certificatesBlue Angel, ENERGY STAR
DisplayLCD
CertificationNordic Swan, GS Mark
Product colorBlack
Market positioningHome & office
Display number of lines1 lines
Internal memory64 MB
Noise level (ready)30 dB
Maximum internal memory- MB
Sound pressure level (printing)49 dB
Sound pressure level (quiet mode)44 dB
Power consumption (off)0.03 W
Power consumption (ready)48 W
Power consumption (standby)6 W
Power consumption (printing)510 W
Energy Star Typical Electricity Consumption (TEC)1.227 kWh/week
Printer fontsBarcode, Bitmap, PCL, Scalable
Maximum duty cycle15000 pages per month
Recommended duty cycle0 - 2000 pages per month
Page description languagesPCL 6
Quantity per pack1 pc(s)
Package depth360 mm
Package width356 mm
Package height183 mm
Package weight7200 g
Cables includedAC
Included cartridge capacity (black)700 pages
Cabling technology10/100Base-T(X)
Security algorithmsSMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print), SNTP Client
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print)
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Custom media width76.2 - 215.9 mm
Custom media length127 - 355.6 mm
Duplex media weight60 - 105 g/m²
Paper tray media typesPlain paper, Recycled paper
Paper tray media weight60 - 163 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
Multi-purpose tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 230 g/m²
Total input capacity250 sheets
Total output capacity150 sheets
Total number of input trays1
Multi-Purpose tray input capacity1 sheets
Weight and Dimensions IconWeight and Dimensions
Depth283 mm
Width438 mm
Height519 mm
