Brother HL-L2372DN User Manual

2-21
Confidential
3.2 Error Message
The error messages displayed on the LCD and LED of the machine and their description are
shown in the table below.
3.2.1 LCD models
Error message
Description
Error
codes
Refer
to:
Initial display Scroll
Cannot Detect Put the Drum Unit
back in.
New process sensor could not
detect the new drum unit
correctly.
4F05 2-39
Put the Toner
Cartridge back in.
Toner cartridge is not
recognized by the cartridge
sensor.
2400 2-37
Cartridge
Error
Put the Toner
Cartridge back in.
The new toner sensor of the
toner cartridge could not detect
a new cartridge properly.
4F01 2-39
New toner box sensor could not
detect the new toner box
correctly.
5E00 2-39
Cooling Down Wait for a while
The side thermistor detected a
temperature higher than the
specified value.
6801 2-43
Cover is Open Close the Front
Cover.
The front cover sensor detected
that the front cover was open.
6001 2-40
Close the Fuser
Cover which can be
found behind the
Back Cover of the
machine.
The eject sensor detected that
the fuser cover was open.
6004 2-40
Drum ! Slide the Green tab
on Drum Unit.
Electric discharge that may be
caused by dirt on the corona
wire of the drum unit was
detected.
6A00 2-44
Drum End
Soon
-
Number of the drum unit
rotations reaches the upper limit
soon.
4000 2-38
Ignore Data -
Detected undecodable data
during printing.
Received undecodable PS data.
--- 4.11.1
Jam 2-sided Pull out the 2-sided
Tray at the back of
the machine and
remove the jammed
paper.
After the first side is printed in 2-
sided printing mode, the
registration front sensor does
not detect paper pass after a set
period of time.
7800 2-46

Brother HL-L2372DN Specifications

General

Color	No
N-up printing	2, 4, 6, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	9 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Sustainability certificates	Blue Angel, ENERGY STAR
Display	LCD
Certification	Nordic Swan, GS Mark
Product color	Black
Market positioning	Home & office
Display number of lines	1 lines
Internal memory	64 MB
Noise level (ready)	30 dB
Maximum internal memory	- MB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
Power consumption (off)	0.03 W
Power consumption (ready)	48 W
Power consumption (standby)	6 W
Power consumption (printing)	510 W
Energy Star Typical Electricity Consumption (TEC)	1.227 kWh/week
Printer fonts	Barcode, Bitmap, PCL, Scalable
Maximum duty cycle	15000 pages per month
Recommended duty cycle	0 - 2000 pages per month
Page description languages	PCL 6
Quantity per pack	1 pc(s)
Package depth	360 mm
Package width	356 mm
Package height	183 mm
Package weight	7200 g
Cables included	AC
Included cartridge capacity (black)	700 pages
Cabling technology	10/100Base-T(X)
Security algorithms	SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, SMTP Client, IPP/IPPS, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print), SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, SMTP Client, FTP Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, Web Services (Print)
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 230 g/m²
Total input capacity	250 sheets
Total output capacity	150 sheets
Total number of input trays	1
Multi-Purpose tray input capacity	1 sheets

Weight and Dimensions

Depth	283 mm
Width	438 mm
Height	519 mm
