5-40
Confidential
*1
01 to 10 will be displayed for “##” in chronological order. Pressing the [OK] while the
machine error log is displayed shows “PGCNT:00000000 (total pages printed at the time of
the error)” on the LCD, and pressing the [OK] again returns the LCD display to machine
error log.
*2
The serial number can be changed according to the procedures below.
1) Press the [▲] or [▼] while the serial number is displayed to display “9” on the LCD, and
press the [OK]. LCD displays the serial number again.
2) Enter the “4”, “7” and “5” in this order as described in the procedure 1). Serial number is
displayed on the LCD. The first digit starts flashing to indicate that it is editable.
3) Press the first digit of the serial number on the keypad, [▲] or [▼] to display the first
number of the serial number on the LCD, and press the [OK]. The second digit starts to
flash. Enter the second digit to the 15th digit similarly.
4) Press the [Go], and the new serial number is saved. The machine returns to the initial
state of maintenance mode.
*3
Pressing the [OK] while the number of each consumable part had replaced is displayed
shows “DATE_XX:000000” (XX: each consumable part) and the replaced date on the LCD.
*4
01 to 10 will be displayed for “##” in chronological order. Pressing the [OK] while the
machine error log is displayed shows “TM:00000 BT:000 (TM: minutes passed from the
previous error, BT: number of times that the power is turned ON/OFF)” on the LCD. Pressing
the [OK] again returns the LCD display to machine error log.
*5
01 to 10 will be displayed for “##” in chronological order. Pressing the [OK] while log for design
analysis is displayed shows “PGCNT:00000000 (total pages printed at the time of the error)”
on the LCD. Pressing the [OK] again returns the LCD display to log for design analysis.
*6
Pressing the [OK] while the SSW information 1 is displayed changes the display to the SSW
information 2.
ENVTYP:00000000 Total printed pages of envelope, thick envelope, and thin
envelope
LABEL:00000000 Printed labels
HAGAKI:00000000 Printed postcards
TTL_JAM:00000000 Total paper jams that have occurred
MP_JAM:00000 Paper jams that have occurred in the MP tray (MP models only)
TR1_JAM:00000000 Paper jams that have occurred in paper tray
IN_JAM:00000000 Paper jams that have occurred in the machine
RE_JAM:00000000 Paper jams that have occurred at the ejecting section or back
cover
DX_JAM:00000000 Paper jams that have occurred in the duplex tray
POWER:00000375 Total power distribution time (hour)
PWRCNT:00000001 The number of times that the power is turned ON
KTN_CH:0000 The number of times that the toner cartridge has been replaced
DRUM_CH:0000
The number of times that the drum unit has been replaced
*3
KTN_PG1:00000000 Pages printed with the current toner cartridge
KTN_PG2:00000000 Pages printed with the previous toner cartridge
KDEV_BIAS:400V Developing bias voltage value
ENGERR##:000000
Engine error log (last ten errors)
*4
HODN_ER:0000 The number of discharge errors occurred
FUSR_ER:0000 The number of fuser unit errors occurred
MTLK_ER:0000 The number of polygon motor errors occurred in the laser
scanner
DEVSTATUS__##:00
Log for design analysis
*5
FUNC1:0000000000
SSW information 1
*6
LCD Description
