2-63
Confidential
Error code 9301
When paper was fed from the MP tray, the MP paper empty sensor detected that no paper
was in the MP tray.
<User Check>
Load paper to the MP tray.
Error code 9302
When paper was fed from the paper tray, the T1 paper empty sensor or T1 paper feed sensor
detected that no paper was in the paper tray.
<User Check>
Set paper in the paper tray.
Step Cause Remedy
1
MP paper empty actuator caught
in some sections of the machine
Reattach the MP paper empty actuator.
2
Connection failure of the MP paper
empty sensor PCB harness
Reconnect the MP paper empty sensor
PCB harness.
3
Connection failure of the MP
relay PCB harness
Reconnect the MP relay PCB harness.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the T1
paper empty/paper feed sensor
harness (paper empty sensor
models only)
Reconnect the T1 paper empty/paper feed
sensor harness.
2
Connection failure of the T1
clutch harness
Reconnect the T1 clutch harness.
3
Connection failure of the paper
feed motor flat cable
Reconnect the paper feed motor flat
cable.
4
T1 paper feed actuator caught in
some sections of the machine (non
paper empty sensor models only)
Reattach the T1 paper feed actuator.
5
T1 paper empty actuator caught in
some sections of the machine
(paper empty sensor models only)
Reattach the T1 paper empty actuator.
6 Abrasion of the PF kit 1 Replace the PF kit 1.
7
Paper feed motor flat cable
failure
Replace the paper feed motor flat cable.
8 T1 clutch failure Replace the T1 clutch.
9
T1 paper feed sensor PCB
failure (non paper empty sensor
models only)
Replace the T1 paper feed sensor PCB
ASSY.
10 Paper feed motor failure Replace the paper feed motor.
11
Damaged gears in the paper
feed drive system
Replace the frame L unit.
12 Main PCB failure Replace the main PCB ASSY.
