Error code 9309
Detected that there was no paper set in all trays when TrayAuto was selected for printing.
<User Check>
• Set paper in the paper tray.
Error code 9701
For 2-sided printing, paper size setting of the printer driver that was not supported by 2-sided
printing was selected.
Error code 9702
For printing by feeding paper from the paper tray, the size of paper specified from the driver
set the size which was not supported by the paper tray.
<User Check>
• Select the specified paper size in the driver and set paper with the same size to the specified
paper tray.
Step Cause Remedy
1
Connection failure of the MP
paper empty sensor PCB harness
Reconnect the MP paper empty sensor
PCB harness.
2
Connection failure of the T1
paper feed sensor harness (non
paper empty sensor models only)
Reconnect the T1 paper feed sensor
harness.
3
Connection failure of the T1
paper empty/paper feed sensor
harness (paper empty sensor
models only)
Reconnect the T1 paper empty/paper feed
sensor harness.
4
Connection failure of the T1
clutch harness
Reconnect the T1 clutch harness.
5
T1/MP paper empty actuator
caught in some sections of the
machine (paper empty sensor
models only)
Reattach the T1/MP paper empty
actuator.
6
T1 paper feed actuator caught in
some sections of the machine
(non paper empty sensor models
only)
Reattach the T1 paper feed actuator.
7 Abrasion of the PF kit 1 Replace the PF kit 1.
8
T1 paper empty/paper feed
sensor PCB failure (paper empty
sensor models only)
Replace the T1 paper empty/paper feed
sensor PCB ASSY.
9
T1 paper feed sensor PCB
failure (non paper empty sensor
models only)
Replace the T1 paper feed sensor PCB
ASSY.
10 T1 clutch failure Replace the T1 clutch.
11
Damaged gears in the paper
feed drive system
Replace the frame L unit.
12 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
To Next Page
