5-2
Confidential
1.3 List of Maintenance-mode Functions
* The functions shaded in the table above are user-accessible.
Function
Code
Function Refer to:
01 EEPROM parameter initialization 1.4.1 (5-3)
05 Printout of scanning compensation data 1.4.2 (5-4)
06 Placement of scanner unit in position for transportation 1.4.3 (5-6)
08 ADF performance test 1.4.4 (5-6)
09 Monochrome image quality test pattern 1.4.5 (5-7)
10 Worker switch (WSW) setting 1.4.6 [1] (5-8)
11 Printout of worker switch data 1.4.6 [2] (5-11)
12 Operation check of LCD 1.4.7 (5-12)
13 Operational check of control panel button 1.4.8 (5-13)
25 Software version check 1.4.9 (5-14)
32 Operational check of sensors 1.4.10 (5-15)
33 LAN connection status display 1.4.11 (5-17)
43 PC print function 1.4.12 (5-18)
45 Not-disclosed-to-users functions 1.4.13 (5-21)
52 EEPROM customizing (User-accessible) 1.4.14 (5-22)
53 Received data transfer function 1.4.15 (5-23)
54 Fine adjustment of scan start/end positions 1.4.16 (5-25)
55 Acquisition of white level data 1.4.17 (5-26)
67 Continuous print test 1.4.18 (5-27)
74 Setting by country 1.4.19 (5-28)
77 Printout of maintenance information 1.4.20 (5-31)
78 Operational check of fan 1.4.21 (5-32)
80 Display of machine history (log) 1.4.22 (5-33)
82 Error code indication 1.4.23 (5-37)
87 Sending communication error list 1.4.24 (5-37)
88
Counter reset after replacing the fuser unit and paper
feeding kit
1.4.25 (5-38)
91 EEPROM parameter initialization 1.4.1 (5-3)
99 Exit from the maintenance mode 1.4.26 (5-38)
