Brother MFC-7360N Service Manual

5-40
Confidential
2.2 Parts Life Reset Function
This function is used to reset the relevant part counter when the user replaced a periodical
replacement part with the correct procedure, and also used to forcibly reset the relevant part
counter when an error cannot be resolved because the user did not replace a consumable
part with the correct procedure.
(1) Press the 3 and 9 buttons at the same time in the ready state.
(2) The “Reset Menu” will appear on the LCD. Select the applicable periodical replacement
part or consumable part by pressing the or button and press the OK button.
<Periodical replacement parts or consumable part are indicated on the LCD>
•Drum
(3) Once “1.Reset 2.Exit” appears on the LCD; press the 1 or 2 button.
(4) The machine implements clearing the counter.
2.3 Deletion of User Setting Information, etc.
In this machine, the user setting information is stored in the EEPROM and flash memory of
the main PCB ASSY. You can delete all the data listed below at a time with the procedure
given below.
• Information related to Net
• User setting information
<Operating Procedure>
(1) Press the Menu button while the machine is in the ready state.
(2) Press the or button, then the “Initial Setup” or “General Setup” will appears on the
LCD and press the OK button.
(Which will appear, “Initial Setup” or “General Setup”, depends on the model.)
(3) Press the or button, then the “Reset Menu” will appear on the LCD and press the
OK button.
(4) Press the or button, then the “All Settings” will appear on the LCD and press the
OK button.
(5) The “1.Reset 2.Exit” appear on the LCD.
(6) Press the 1 button, and the user setting information is deleted, and the machine goes
back to the ready state.
Note:
• This function is not available on models without the numeric keys.
• All replacement parts are always indicated on the LCD even though their lives do not
reach the end of life.
• The machine returns to the ready state automatically if no panel operation is
implemented for 30 seconds.
Note:
• The machine returns to the ready state automatically if no panel operation is
implemented for 30 seconds.

Brother MFC-7360N Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Scan to	E-mail, File, Image, OCR
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Dimensions (WxDxH)	405 x 399 x 316 mm
All-in-one functions	Copy, Fax, Print, Scan
Compatible operating systems	Linux Mac OS X 10.4.11, 10.5.x, 10.6x Windows 7, Vista, XP, 2000
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	14.4 Kbit/s
Fax speed dialing (max numbers)	208
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	32 MB
Processor family	ARM
Compatible memory cards	Not supported
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	0.9 W
Power consumption (PowerSave)	65 W
Power consumption (average operating)	495 W
Package weight	14800 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	10000 pages per month
