Brother MFC-7360N Service Manual

5-26
Confidential
1.4.17 Acquisition of white level data (Function code 55)
<Function>
This function allows you to acquire the white level of the scanner unit and save it to the
EEPROM of the main PCB.
<Operating Procedure>
(1) Press the 5 button twice in the initial state of the maintenance mode.
In the case of the model without the numeric keys; Press the or button. The
“MAINTENANCE 55” appears on the LCD. Then press the OK button.
(2) The “Press START” will appear on the LCD. Press the Start button.
The “SCANNER AREA SET” will appear on the LCD.
(3) After a few seconds, the machine saves the compensation of the white level data/
scanning width in the EEPROM, beeps for one second, and returns to the initial state of
the maintenance mode.
Note:
• After deep sleep mode is released, execute this function code. If the correct white level
data is not yet acquired, update the firmware to the latest version. If updating the
firmware is not possible, open and close the front cover, and then retry acquisition after
the main motor has stopped.

Brother MFC-7360N Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Scan to	E-mail, File, Image, OCR
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	600 x 600 DPI
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	24 cpm
Dimensions (WxDxH)	405 x 399 x 316 mm
All-in-one functions	Copy, Fax, Print, Scan
Compatible operating systems	Linux Mac OS X 10.4.11, 10.5.x, 10.6x Windows 7, Vista, XP, 2000
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	14.4 Kbit/s
Fax speed dialing (max numbers)	208
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	32 MB
Processor family	ARM
Compatible memory cards	Not supported
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	0.9 W
Power consumption (PowerSave)	65 W
Power consumption (average operating)	495 W
Package weight	14800 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	10000 pages per month
