3-19
Confidential
12 High voltage power supply PCB ASSY
13 Fuser unit
Main-HVPS flat cable harness
High voltage power
supply PCB ASSY
Main PCB ASSY
Guide
Guide
Guide
Guide
Fuser unit
Heater harness
Center thermistor harness ASSY
Side thermistor harness ASSY
Main frame L ASSY
Main frame R ASSY
Guide
Guide
