Loading documents
25
3
d Adjust the paper guides (1) to fit the
width of your document.
Note
To scan non-standard documents, see
Using the scanner glass uu page 25.
Using the scanner glass 3
You can use the scanner glass to fax, copy or
scan pages of a book, one page at a time.
Document Sizes Supported 3
How to load documents 3
Note
To use the scanner glass, the ADF must
be empty.
a Lift the document cover.
b Using the document guidelines on the
left and top, place the document
face down in the upper left corner of the
scanner glass.
c Close the document cover.
Important
If the document is a book or is thick do not
slam the cover or press on it.
Length: (MFC-8710DW and MFC-8910DW)
Up to 14 in. (355.6 mm)
(MFC-8510DN)
Up to 11.8 in. (300.0 mm)
Width: Up to 8.5 in. (215.9 mm)
Weight: Up to 4.4 lb (2.0 kg)
