Brother MFC-8912DW - 9.34 Internal temperature thermistor

3-97
Confidential
9.34 Internal temperature thermistor
(1) Release the internal temperature thermistor harness from the two hooks and the guide,
and remove the internal temperature thermistor from the main frame L ASSY.
Fig. 3-126
Internal temperature thermistor
Internal temperature
thermistor harness
Internal temperature thermistor harness
Internal temperature thermistor
Guide
Hook
Hook
