48
e Hold the SO-DIMM by the edges and
align the notches in the SO-DIMM with
the protrusions in the slot. Insert the
SO-DIMM diagonally (1), then tilt it
toward the interface board until it clicks
into place (2).
f Put the metal (2) and then the plastic (1)
SO-DIMM covers back on.
g Plug the machine’s power cord back into
the AC power outlet first, and then
connect the interface cable.
h Turn on the machine’s power switch.
Note
To make sure that you have installed the
SO-DIMM properly, you can print the user
settings page that shows the current
memory size. (See User Settings List
on page 105.)
12
1
2
To Next Page
