Brother MFC-J1010DW User Manual

Home > Mobile/Web Connect > Brother Web Connect > Brother Web Connect Overview > Configure the
Proxy Server Settings Using Web Based Management
Configure the Proxy Server Settings Using Web Based Management
If your network uses a proxy server, the following proxy server information must be configured using Web
Based Management:
• Proxy server address
• Port number
• User Name
• Password
We recommend Microsoft Internet Explorer 11/Microsoft Edge for Windows, Safari 10/11 for Mac, Google
Chrome
™
for Android (4.x or later), and Google Chrome
™
/Safari for iOS (10.x or later). Make sure that
JavaScript and Cookies are always enabled in whichever browser you use.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Network > Protocol.
Start from
, if the navigation menu is not shown on the left side of the screen.
5. Make sure the Proxy check box is selected, and then click Submit.
6. In the Proxy field, click Advanced Settings.
7. Enter the proxy server information.
8. Click Submit.
Related Information
• Brother Web Connect Overview
Related Topics:
• Access Web Based Management
332

Brother MFC-J1010DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	17 ppm
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Index card
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO C-series sizes (C0...C9)	C5
Photo paper sizes (imperial)	3.5x5, 4x6, 5x7, 5x8 \
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 300 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, AES, EAP-FAST, EAP-TLS, EAP-TTLS, HTTPS, IPPS, PEAP, SSID, SSL/TLS, TKIP, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Internal memory	128 MB
Duplex copying	-
Maximum copy resolution	1200 x 1200 DPI
Copy speed (black, normal quality, A4)	11.5 cpm
Copy speed (color, normal quality, A4)	4 cpm
Display	LCD
Control type	Buttons, Touch
Product color	Grey, White
Display diagonal	2.67 \
Market positioning	Home & office
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Optical scanning resolution	1200 x 2400 DPI
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8
Fax transmission speed	14400 sec/page
Sustainability certificates	Blue Angel
Package depth	249 mm
Package width	477 mm
Package height	457 mm
Package weight	9700 g
Cables included	AC
Bundled software	NewSoft Presto! PageManager 9 Brother iPrint & Scan, ScanSoft Paperport 14 SE.
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	- pages per month
Number of print cartridges	4
Total input capacity	170 sheets
Total output capacity	50 sheets
Paper tray 1 input capacity	150 sheets
Total number of input trays	2
Auto document feeder (ADF) input capacity	20 sheets
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	400 mm
Height	172 mm
Weight	8100 g
