Brother MFC-J491DW User Manual

Home > Network > Additional Methods of Configuring Your Brother Machine for a Wireless Network > Use
Wi-Fi Direct
®
> Configure Your Wi-Fi Direct Network > Configure Your Wi-Fi Direct Network Using the PIN
Method
Configure Your Wi-Fi Direct Network Using the PIN Method
>> MFC-J491DW/MFC-J497DW
>> MFC-J690DW/MFC-J895DW
MFC-J491DW/MFC-J497DW
If your mobile device supports the PIN Method of Wi-Fi Direct, follow these steps to configure a Wi-Fi Direct
network:
When the machine receives the Wi-Fi Direct request from your mobile device, the message [Wi-Fi
Direct connection request received.] will appear on the LCD. Press c to connect.
1. Press Settings.
2. Press a or b to select the following:
a. Select [Network]. Press OK.
b. Select [Wi-Fi Direct]. Press OK.
c. Select [PIN Code]. Press OK.
3. Activate your mobile device's WPS PIN configuration method (see your mobile device's user's guide for
instructions) when [Activate Wi-Fi Direct on other device.] appears. Press c on your Brother
machine. This will start the Wi-Fi Direct setup.
4. Do one of the following:
• When your Brother machine is the G/O (Group Owner), it will wait for a connection request from your
mobile device. If the LCD prompts you to enter a PIN, enter the PIN displayed on your mobile device in
the machine. Press OK. Follow the instructions, and then go to the next step. If the PIN is displayed on
your Brother machine, enter the PIN in your mobile device.
• When your Brother machine is not the G/O (Group Owner), it will display available device names with
which to configure a Wi-Fi Direct network. Select the mobile device to which you want to connect and
press OK. Search for available devices again by selecting [Rescan].
When [Select PIN Method] appears, do one of the following:
- Press c to display the PIN on your machine and enter the PIN in your mobile device. Follow the
instructions, and then go to the next step.
- Press d to enter a PIN shown on your mobile device in the machine, and then press OK. Follow the
instructions, and then go to the next step.
5. If your mobile device connects successfully, the machine displays [Connected]. You have completed the
Wi-Fi Direct network setup.
MFC-J690DW/MFC-J895DW
If your mobile device supports the PIN Method of Wi-Fi Direct, follow these steps to configure a Wi-Fi Direct
network:
When the machine receives the Wi-Fi Direct request from your mobile device, the message [Wi-Fi
Direct connection request received. Press [OK] to connect.] will appear on the LCD.
Press [OK] to connect.
1. Press [Settings] > [All Settings] > [Network] > [Wi-Fi Direct] > [PIN Code].
2. Activate Wi-Fi Direct on your mobile device (see your mobile device's user's guide for instructions) when
[Activate Wi-Fi Direct on other device. Then Press [OK].] appears. Press [OK] on your
Brother machine.
354

Brother MFC-J491DW Specifications

General

Display	LCD
Product color	Black
Built-in display	Yes
Display diagonal	1.77 \
Market positioning	Home & office
Internal memory	128 MB
Card reader integrated	No
Sound pressure level (copying)	50 dB
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	6 ipm
Time to first page (black, normal)	8 s
Duplex print speed (ISO/IEC 24734) mono	3 ipm
Duplex print speed (ISO/IEC 24734) color	1.7 ipm
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	10 ppm
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Package depth	249 mm
Package width	447 mm
Package height	457 mm
Package weight	10100 g
Power consumption (off)	0.2 W
Power consumption (sleep)	1 W
Power consumption (standby)	3.5 W
Power consumption (printing)	16 W
Power consumption (average operating)	- W
Sustainability certificates	Nordic Swan Ecolabel, ENERGY STAR
Faxing	Mono faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Paper input type	Paper tray
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Paper tray media types	Plain paper
Borderless printing media sizes	A4
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed & ADF scanner
Input color depth	30 bit
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Digital sender	-
Maximum duty cycle	- pages per month
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	341 mm
Width	400 mm
Height	172 mm
